Protect this device from shocks and abuse. Avoid brute force when operating the device.

Familiarise yourself with the functions of the device before actually using it. Do not allow operation
by unqualified people. Any damage that may occur will most probably be due to unprofessional use
of the device.

All modifications of the device are forbidden for safety reasons. Damage caused by user modifications
to the device is not covered by the warranty.

Only use the device for its intended purpose. All other uses may lead to short circuits, burns,
electroshocks, lamp explosion, crash, etc. Using the device in an unauthorised way will void the
warranty.

Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and
the dealer will not accept responsibility for any ensuing defects or problems.

Mechanical wear and LEDs are not covered by warranty.

A qualified technician shall install and service this device.

Do not switch the device on immediately after it has been exposed to changes in temperature.
Protect the device against damage by leaving it switched off until it has reached room temperature.

This device is designed for professional use on stage, in discos, theatres, etc. The device shall only
be used indoors with an alternating current of 230 VAC, 50 Hz.

Lighting effects are not designed for permanent operation: regular operation breaks will prolong their
lives.

Use the original packaging if the device is to be transported.

Keep this manual for future reference.
4. Features

create amazing effects and video animations with the individual pixel control

can be used as wash-effect, pixel video control, or even as blinder effect

can be controlled without DMX with our pre-programmed effects in stand-alone, master/slave or
music mode

several DMX modes from simple to professional control via DMX
9-channel mode: dimmer, shutter, programme, speed programme, RGBW-A
o
24-channel mode: dimmer, shutter, programme, speed programme, RGBW-A (4 segments)
o
60-channel mode: RGBW-A (12 segments)
o

clear LED display for easy settings

electronic dimming 0-100%
5. Overview
Refer to the illustrations on page 2 of this manual.
1
ventilation holes
2
powerCON input and output
3 safety cable attachment
6. Installation
Choose a suitable mounting spot. Connect the power cord to the mains. Switch off and disconnect after
use.

Mounting the Device


Have the device installed by a qualified person, respecting EN 60598-2-17 and all other applicable
norms.

The carrying construction must be able to support 10 times the weight of the device for 1 hour
without deforming.

The installation must always be secured with a secondary attachment e.g. a safety cable.

Never stand directly below the device when it is being mounted, removed or serviced. Have a
qualified technician check the device once a year and once before you bring it into service.
V. 01 – 24/09/2014
VDPL1212RGBWA
4
5
6
4
DMX input and output
LCD display
control panel
