Channel
5 (Prism)
6 (Prism Rotate)
7 (Empty)
8 (Frost)
9 (Focus)
10 (X)
11 (X fine)
12 (Y)
13 (Y fine)
14 (Macro Function)
15 (Reset)
V. 03 – 29/01/2013
VDP200MH5R
DMX value
40-43
44-47
48-51
52-55
56-59
60-63
64-67
68-71
72-113
114-117
118-159
160-166
167-172
173-179
180-185
186-191
192-198
199-204
205-211
212-217
218-223
224-230
231-236
237-243
244-249
250-255
0-127
128-255
0-20
21-41
42-62
63-83
84-104
105-126
127
128-190
191-192
193-255
0-255
0-255
0-255
0-255
0-255
0-255
0-255
0-11
12-24
25-37
38-50
51-62
63-255
128
8
Description
Gobo 10
Gobo 11
Gobo 12
Gobo 13
Gobo 14
Gobo 15
Gobo 16
Gobo 17
Gobo change, fast to slow
Stop
Gobo change, slow to fast
Gobo 2, slow to fast
Gobo 3, slow to fast
Gobo 4, slow to fast
Gobo 5, slow to fast
Gobo 6, slow to fast
Gobo 7, slow to fast
Gobo 8, slow to fast
Gobo 9, slow to fast
Gobo 10, slow to fast
Gobo 11, slow to fast
Gobo 12, slow to fast
Gobo 13, slow to fast
Gobo 14, slow to fast
Gobo 15, slow to fast
Gobo 16, slow to fast
White
Prism
Angle 0
Angle 90
Angle 180
Angle 270
Angle 360
Angle 450
Angle 540
Fast rotate to Slow rotate
Stop
Slow rotate to fast rotate
0-100% Frost
0-100% Focus
540°
1.8°
270°
1.8°
Reset
