Start-up

After the proper installation of the KVM extenders they can be immediately put into
operation.
Mind the following activation sequence when starting the modules:
1. Turn on the user module
2. Turn on the computer module
3. Turn on the computer that is connected to the computer module.
NOTE: The recommended activation sequence ensures that the KVM extenders
are able to read out the features of the connected monitor and to transmit them to
the computer (see DDC transmission with cache function on page 57).

Starting process

After the computer module and the user module are turned on, the LEDs on the
front panel show the module's operating status.
For further information about this topic, also see the chapter Status LEDs on
page 61 ff.

On-screen display of the user module

When starting the user module, information about the starting process as well as the
firmware versions and IDs of the connected modules are displayed in the monitor of
the user module.
Additionally, the local hotkey
module and the remote OSD
OSD of the computer module are shown.
ADVICE: Press
Pause
DL-DVI-Vision-IP-Fiber-CON
DL-DVI-Vision-IP-Fiber-CPU
(default: Alt + Num
remote hotkey
to stop the process. Pressing
.
.
) to open the local OSD of the user
(default: Ctrl + Num ) to open the remote
continues the process.
Space
G&D DL-DVI-Vision-IP-Fiber · 10
