The LEDs on both the front and the back panel of the computer module and the
user module let you control the operational status of the KVM extender at any time.
Meaning of the LEDs on the front panel
Area
LED
Ident.
Ident.
Power
Red.
Main
Status
K/M
System
Video
Pairing
61 · G&D DL-DVI-Vision-IP-Fiber
Color
Status
blue
on
green
on
off
green
on
off
green
on
blinking
green
on
blinking
fast
blinking
red
on
yellow
on
off
yellow
on
off
Meaning
On as soon as the LED has been activated
via web application.
The optional power pack is connected and
supplies voltage of 12 Volt.
The optional power pack is not (properly)
connected.
The power pack is switched on and sup-
plies the required voltage.
The power pack is switched off or a con-
nection to the power network could not
be established.
The keyboard has been detected.
No keyboard connected or keyboard could
not be detected.
Device is ready for operation.
Executing update.
Device is reset to default settings after
pushing the Reset button for a long time.
Internal error
A stable video signal has been detected at
the video input.
The incoming video signal could not be
detected or its quality is not good enough
to be processed.
The connection to the remote station has
been established.
The connection to the remote station
could not be established.
