Menu overview

The following table shows the complete menu structure. A menu item can be selected within a level by
using the up and down keys. The next sub level can be selected by the cursor right key. The cursor left
key can be used to move back to a higher level.
Main menu
Start menu
1. Scheduler
2. Show
3. Port IN
4. Port Out
5. RDM DMX 1
6. RDM DMX 2
Submenu 1 Submenu 2
Enable
Scheduler
(On/Off)
Stop Show
Run Show
XXXX.wds
...
Wind Speed
Toggle Out N
...
Device List D#001 A001
Onl
Varionaut 150
...
New Discovery
Submenu 3 Description
Show model type and current system time
Show operation mode of the scheduler
Activate / deactivate scheduler
Show running showname and time
Stop running show
Select one show from the SDCard and play
show
Show status of digital inputs as 0/1
Show the current wind speed in meters /
hour. (if the Oase wind anemometer is
connected)
Show status of status of digital outputs.
Switch the outputs on or off by pressing
ENTER.
Show the count of RDM devices at Port 1 or
Port 2.
List of all RDM devices:
D#001: Device Number
SD#001: Sub device Number
Device ID Show the RDM Device-ID
Reset Device The device receives the RESET command
by pressing ENTER.
Identify Device Choose IDENTIFY mode for the device to
discover it on the field.
DMX Address Show and edit the current DMX Address.
Device Info Show the RDM Device Info of the device.
Device Label Show the RDM Device Label of the device.
Device Hours Show the operating hours of the device.
Manufacturer Show the manufacturer label of the device.
Softwareversion Show the version label of the firmware.
Personality Show and select the RDM Personality of the
device.
Sensors Show the sensor values.
Clear the current device list and start search
all devices.
