LEDs at the back panel
The back panel of the IP matrix switch provides additional status LEDs. The LEDs
have the following function:
Interface LED
Device Status
Fail
Ready
Ident.
Network A yellow
green
Network B yellow
green
Status Meaning
on Device is ready for operation.
off Defective internal communication.
on The LED to identify the device in the web application is
activated.
off The device is ready for operation or turned off.
blinking Device is ready for operation or is being booted.
off Defective internal communication.
on The LED to identify the device in the web application is
activated.
on Active connection
blinking Activity at network interface
on Active connection
blinking Activity at network interface
Status displays
