Status displays

Status displays
LEDs at the front panel
The LEDs on the front panel of the IP matrix switch show the system's operating sta-
tus:
Section LED
Ident. Ident.
Power Red.
Main
Device Ready
System
20 · G&D ControlCenter-IP
Status Meaning
on The LED to identify the device in the web application is
activated.
aus The device is ready for operation or turned off.
on The power pack is turned on and supplies the required
voltage.
off The power pack is turned off or the connection to the
mains could not be established.
on The power pack is turned on and supplies the required
voltage.
off The power pack is turned off or the connection to the
mains could not be established.
blinking Device is ready for operation or is being booted.
off Defective internal communication.
green Device is ready for operation.
blinking Restoring the default settings after pressing the
green reset button
red The device is not ready for operation.
off Defective internal communication.
