Basic configuration of the KVM-over-IP™ connection
6. Click on
Add end devices
The window shows two tables listing any found end devices (right column) and
end devices you have taken over (left column):
Take over devices:
Found devices:
7. In the table on the right, select one or more devices found that you want to add as
end device(s) of this IP matrix switch.
8. Click on (left arrow key) to move the device(s) to the list of the devices to be
taken over.
NOTE:
You can also click on
device you want to add to the matrix switch.
9. Click on Apply to add the selected end devices to the matrix switch.

Determination of the type of video transmission

In the default setting, the target modules (
cast to the user modules (
This option allows users with »Target multi access« right to connect to a computer
to which another user is already connected.
IMPORTANT:
The multicast streams are controlled by the network switches and
enable efficient distribution of the streams to multiple recipients at the same time.
Please note the requirements for the network switch for sending the video streams
via multicast. Refer to the Installation Guide for detailed information.
Alternatively, you can specify that the target modules (
streams via unicast to the user modules (
The connection of a user to a computer to which another user is already connected
is not possible in this mode (message:
NOTE: This option places significantly less demands on the network switch.
You can define the type of video transmission system-wide. The system-wide setting
is applied by default by all target modules. In addition, you can specify the type of
video transmission individually for each target module.
14 · G&D ControlCenter-IP
on the context menu.
List of end devices, which can be added
to the IP matrix switch.
List of all end devices found in the network
New to manually enter the hostname of an end
IP-CPU
IP-CON ).
IP-CON
No multicast video
) send the video streams via multi-
IP-CPU
).
)!
) send the video
