Elektrische Installation
9
4
4
8
7
6
5
4
1
U, V, W (Motorphasen)
2
M
, M
T1
3
PE
4
Dichtung zwischen Motor und Motorhalterung
5
Motorkabel
Abbildung 4.5 Den FCP 106 am Motor anschließen
24
VLT® DriveMotor FCP 106/FCM 106
(Motor-Thermistorkabel)
T2
Danfoss A/S © 11/2015 Alle Rechte vorbehalten.
10
M
M
PE
T1
6
Adapterplatte
7
Motoranschlussdichtung
8
Motorstecker
9
Frequenzumrichter
10
Befestigungsschraube
W
V
U
T2
1
3
2
MG03L303
