Single zone DEOL Calculation Example
Event Default (Ohm)
TAMPER (SHORT) 0
STANDBY 4K7
ALARM 9K4
TAMPER (OPEN) Inf.
Example using 4k7 Tamper and 4k7 Alarm resistors. Remove
all jumpers for isolated outputs.
Table 1: Connections
Terminal Label
1 LED
2 TEST
3, 4 FAULT/MASK
4, 5 TEOL
5, 7 DEOL
5, 6 ALARM N/C
7, 8 TAMPER N/C
9, 10 ALARM N/O
11, 12 +, − 12V DC
Multibeam alignment and masking
The multifunction lens fitted to the DDI602AM detector
produces seven long-range beams and seven medium- to
short-range curtain PIR beams. The PIR circuitry detects
changes in heat and movement in the beam pattern; therefore
items such as trees, shrubs, ponds, boiler flues, and animals
should be considered when positioning the detector. The
microwave module detects actual movement towards or away
from the detector and is programmed to ignore any objects that
move outside of the preselected detection range.
The detector module is fitted with two sliding shutters to reduce
the detection angle.
The curtains are fitted to the pan and tilt module as shown in
Figure 6. Each section of the detector lens gives a coverage
pattern of approximately 10 degrees.
An additional set of curtain sliders is provided should the beam
pattern be narrowed even further, e.g. if the minimum detection
angle of 10 degrees is required.
When coverage exceeds the desired detection area, adjust the
module as required and mask off any beams, either vertically
or horizontally, to avoid unwanted detection.
Use portions of the self-adhesive silver mask applied to the
rear, smooth side of the lens as shown in Figures 9 to 12.
Gently lift the top and bottom edges of the pan and tilt module
to release the lens. To replace the lens, please begin by sliding
one side of the lens into the clips on the pan and tilt module.
After one side is secure, do the same for the opposite side.
Once both sides are secure, gently lift the top and bottom
edges of the pan and tilt module and press on the lens to click
it into place.
Always replace the lens the correct way up to ensure exact
beam pattern coverage. The top of the lens is marked TOP as
shown in Figure 7. There is a locating notch on the top of the
pan and tilt module that locates into the cut-out on the top of
the lens.
P/N 146655999-1 • REV A • ISS 30JUN14
CALCULATION
CLOSED CIRCUIT
Rt
Rt + Ra
OPEN CIRCUIT
Description
Remote LED enable
Remote TEST input
Fault/Anti-Mask relay normally closed
Triple End-of-Line resistors
Double End-of-Line resistors
Alarm relay, normally closed
Tamper relay, normally closed
Alarm relay, normally open
12 V DC power supply
Table 2 below summarizes typical masking configurations for
use when the range option is set to 30 meters.
Table 2: Masking configurations for maximum range
Configuration Height
(m)
Multibeam, optimum 3
Multibeam 6
Pet immunity [1] 1.5
Curtain coverage [2] 6
[1] Black area should be masked for pet alley applications up to
30 meters.
[2] Black area should be masked for curtain coverage applications.
Figure 9 shows the side view for the mounting height of 3 m.
Figure 9 legend
Item Description
1. Long range, 30 m section
2. Short/ medium range, 6 m to 20 m section
Figure 9 note: EN50131-2-2 Grade 3 compliance requires 3m
mounting height and 0º adjustment, or 1.5m mounting height
and -2º adjustment.
Figure 10 shows the side view for the mounting height of 6 m.
Figure 10 note: This setup has not been tested to EN50131-2-
2.
Figure 11 note: Mask the black marked section off for pet
alley applications up to 30 m.
Figure 12 notes: This setup has not been tested to EN50131-
2-2. Mask the black marked section off for curtain coverage
applications.
Figure 13 shows the pattern for the maximum range in the
optimum position (see Figure 9). Masking the top section of the
lens reduces the range to 20 m.
Figure 14 shows the pattern for the minimum range (10 m). In
this case masking the top section of the lens reduces the range
to 6 meters.
Figure 13 and 14 legend
Item Description
1. Microwave coverage
2. PIR coverage
LEDs
LEDs are shown on Figure 17.
Figure 17 legend
Item Colour
1. Red
2. Green
3. Red (small)
4. Blue
5. Infrared
Tilt (°) Max. range Reference
(m)
0 30 Figure 9
9 25 Figure 10
−2 30 Figure 11
45 5 Figure 12
Description
PIR active
Microwave active
Anti-Mask
Detection alarm
Walk tester communication
