Dimensional drawings
Dimensional drawing IMA-ICT 2 (immersion fitting)
Fig. 10: Dimensional drawing IMA-ICT 2 (immersion fitting) (all measurements in mm)
I. Immersion depth 1000
Flange
Ø D
Ø K
Ø d
2
b
Ø a
Screws
68
I.
DN 80/PN 16
200
160
8 x 18
20
63.5
M 16
A1853
