Functional description
1,4
1,2
I.
1,0
2
0,8
0
Fig. 3: Dependence of the installation factor on the distance from the wall
[f]
I. Installation factor
[a]
II. Distance from wall
[f] dependent on the distance of the sensor from the wall [a] (for
The installation factor
electrically isolating pipes (1) and electrically conducting pipes (2))
50
1
10 20
II.
30 40 50 mm
A1847
