Fig. 2: Construction of the sensor
10. Sensor cable
11. Lock nuts G 3/4" (supplied by cus‐
tomer)
12. Chemraz
® seal
13. Sensor head with hole
2.2

Cell constant and installation factor

The electrolytic conductivity of the liquid predominantly depends on the ion concentration.
The geometrical conditions of the sensor surroundings and the geometry of the sensor
itself have to be taken into consideration with the measurement.
The geometry of the sensor is fully described by the cell constant
The geometrical conditions of the sensor surroundings are described by the installation
[f] . The installation factor [f] does not need to be considered if the sensor head is
factor
sufficiently far away from the wall (
installation factor is higher than 1 with electrically isolating pipes (1) and lower than 1 with
electrically conducting pipes (2), see Fig. 3
10
11
12
13
[a] > 30 mm). With smaller gaps from the wall, the
Functional description
A1846
[ZK] .
