EN
Attaching the Extension Hose/Long Nozzle/Wide Nozzle
Attaching the Round Brush Nozzle/Bent Nozzle
3. When you want to remove the attachments, simply pull the attachments off the de-
vice, the extension hose or the long nozzle.
Attaching the Cleaning Cloth
1. The cleaning cloth is pulled over the wide nozzle. Make sure that the cloth is fi tted
correctly.
2. When you want to remove the cleaning cloth, simply pull it off the wide nozzle. Be
careful when removing the cleaning cloth as it gets hot during use!
Attaching the Window Squeegee
3. To detach the window squeegee, pull the front hook back and unhook the wide nozzle.
22
1. Place the extension hose, the long nozzle or the wide
nozzle onto the device.
2. Then turn the extension hose, the long nozzle or the
wide nozzle (see marking on the respective attachment)
to lock the attachment in place.
3. When you want to remove the attachments, turn the at-
tachment counter to the arrow marking on the respec-
tive attachment and detach it from the device.
1. Place the round brush nozzle or the bent nozzle directly
onto the device or onto the adapter hose. Make sure
that the attachment is seated fi rmly in place.
2. Alternatively, the long nozzle can be used as a kind of
adapter between the device/extension hose and the
round brush nozzle/bent nozzle (see picture).
1. Insert the hooks on the bottom end of the squeegee into
the mounts which are provided for them on the bottom
end of the wide nozzle.
2. Fold down the wide nozzle so that the nozzle attachment
can engage on the front hook of the squeegee.
