7.7 Overview of the controllers

7.7.1 LBG Transformer controller for LBM/LBC

•
1, 2 or 3 drives can be controlled.

7.7.2 LBS/LBS2+1 synchronisation control for LBM/LBC

•
Version 1: 2 drives can be controlled synchronously.
•
Version 2: 2 drives can be controlled synchronously + 1 drive cannot be controlled
synchronously.

7.7.3 Synchro power control

•
Up to four drives can be controlled synchronously, up to three memory positions can be saved.

7.7.4 Multi Control duo

•
One to two drives can be controlled synchronously (with 20% duty cycle).
•
Up to maximum 12 A current output
