FLM-420/4-CON Conventional Interface Module for 4-wire LSN
Functional description
The FLM-420/4-CON Conventional interface module enables monitored connection of conventional detectors to LSN
fire panels via a 4-wire supply network (LSN with external power supply).
The surface-mount housing for the FLM-420/4-CON-S has pre-formed conduit connections and rubber bushings for
cable entries (Figure 2, page 7, Removal: Figure 1, page 6, Installation: Figure 5, page 9).
The FLM-420/4-CON-D is installed on a DIN rail in accordance with EN 500022 with enclosed adapter (Installation:
Figure 6, page 10; Removal: Figure 7, page 11).
Address setting
Fit a rotary switch in the required position using a pan head slotted screwdriver (see Figure 8, page 12).
It is not permitted to use different operating modes in one loop/stub/T branch next to each other!
Address (A) Operating mode
0 0 0 Loop/stub in LSN improved version mode with automatic addressing
0 0 1 ... 2 5 4 Loop/stub/T branches in LSN improved version mode with manual addressing
CL 0 0 Loop/stub in LSN classic mode (address range: max. 127)
2 5 5 ... 2 9 9 Non-permitted address range (error message on fire panel)!
Connection
Connection to LSN
With power supply via LSN additional power supply
With power supply via external power supply unit (free-of-ground)
Connection of conventional lines
2 stubs (Class B)
1 stub (Class B)
1 loop (Class A)
Description
LSN: b1+ | a- | b2+
AUX: 2+ | 1/2- | 1+
OUT1: + | -
OUT2/IN1: - | +
PWR IN
LSN AUX or EXT.PWR: + | -
* Does not apply if connecting 2-wire detectors
Technical specifications
LSN
Primary line
Power supply input (PWR IN) Voltage
Power supply output, 4-wire
detector
EOL resistor for zone as stub (Class B)
Permissible wire diameter
Permissible operating temperature / storage temperature
Permissible relative humidity
Protection class as per IEC 60529
Safety class as per IEC 60950
EMC interference immunity/EMC emitted interference
Housing material and color
Dimensions
Bosch Sicherheitssysteme GmbH
Function
LSN b incoming / LSN a / LSN b outgoing
Power supply output, 4-wire detector
Stub 1 or outgoing loop
Stub 2 or incoming loop
Power supply input (from LSN or external)
Input voltage
Max. current consumption
Line voltage
Max. line current
Max. line resistance
Ripple
Voltage
Max. current
Ripple
Surface-mount housing
Interface housing and adapter
FLM-420/4-CON-S
FLM-420/4-CON-D
Installation Guide
See ...
Figure 10, page 13
Figure 11, page 13
See ...
Figure 12, page 14, left
Figure 12, page 14, right
Figure 13, page 15
15 to 33 V DC (min. to max.)
8.5 mA
21 to 22 V DC (21,5 V DC typ. ±0,5 V DC)
80 mA (±10% @ 25 °C)
50 Ω per line (2 x 25 Ω max.)
24 to 30 V DC (min. to max.)
< 150 mV
23.5 to 30 V DC (rated voltage 24 V DC)
200 mA per output (can be switched in parallel)
< 300 mV
With calibration value: 2,2 kΩ
Without calibration value: 2,2 kΩ / 3,9 kΩ
2
0.6 to 3.3 mm
-20 °C ... +55 °C / -25 °C ... +80 °C
<96%, non-condensing
FLM-420/4-CON-S: IP 54
FLM-420/4-CON-D: IP 30
III
EN 54-18, EN 50130, VDS 2540/EN 61000-6-3
ABS/PC blend, signal white (RAL 9003)
PPO (Noryl), gray white (similar to RAL 9002)
approx. 126 mm x 126 mm x 71mm (W x H x D)
approx. 110 mm x 110 mm x 48 mm (W x H x D)
