CAUTION:
During the installation make sure that the top side of the units is located horizontally.
The drain pan is designed with a little gradient to facilitate drain.

Air Duct Connection

1. Circulatory air pressure drop should be within External Static Pressure.
2. Galvanized steel air ducts are suitable.
3. Make sure there is no leak of air.
4. Air duct should be fire-proof, refer to national and local regulations of the country
where the units is being installed.

Pipe Connections:

1. When the water inlet and outlet connections are made, make sure that there are no
hot or cold water on the system and the valves are closed.
2. In case of contact with the hot water, burns may occur on contact area.
3. Use appropriate fittings for water connections. Refer to the specifications.
4. The lower connection is the water inlet while the upper is the outlet.
5. Seal must be used in water connections against leakage.
6. Drain pipe can be PVC or steel.
7. The suggested slope of the drain pipe is minimum 1:50.
Wiring
1. All wiring connection must be done according to the wiring diagram on the units and
inside the manuel.
2. The units must be GROUNDED well.
3. All field wiring must be installed in accordance with the national regulations that apply.
4. Power supply cable must be equivalent to H05RN-F (2451EC57) as minimum
requirement.
5. Ensure that appropriate voltage value and cables are supplied to the units.
6. While making this unit's electrical connections, there must not be any energy on the
main supply cable and main switch has to be switched off.
7. During the installation of electrical connections, make sure the cables are connected
firmly.
8. An appropriate strain relief unit must be used to attach the power wires to the terminal
box.
WARNING!
The responsibilities for any malfunctioning or damage caused by accessories which are
not supplied with the unit belong to the supplier of the accessory.
14
