How to Use the AIT Auto Loader Unit

18
Chapter 2 Operation
1
Be sure to push the cartridges all the way into the magazine. If the
cartridges are not pushed in all the way, the hook on the magazine
protrudes outward, and will prevent magazine insertion into the
Autoloader.
Good
Hook not protruding
2
Ensure that the BUSY and TAPE indicators off, insert the magazine.
When the magazine is loaded, the following actions occur:
• After "Magazine Loading" appears, checking of the magazine starts.
• If the magazine is write-protected, the write-protect indicator (
• All cartridges are checked in order.
• As each cartridge is checked, its number blinks.
3
"Scan4 Ok" should be displayed, when all cartridge numbers display on
the LCD, a cartridge to be loaded into the AIT drive may be selected by
computer software or by the SELECT or ENTER buttons on the
machine. When a cartridge is loaded into the AIT drive, the TAPE
indicator lights.
4
Data may be read or written on the tape using computer software. While
reading or writing, the BUSY indicator lights.
Bad
Hook protruding
Inserting the magazine
Hook protruding
) appears.
