Loading Cartridges

Four data cartridges should be loaded in the magazine.
Cautions:
• Always load four cartridges into the magazine. Make sure that cartridges
are correctly oriented. Damage may result if fewer than four cartridges are
loaded or if the cartridges are loaded incorrectly.
• Incorrect cartridge orientation prevent insertion of the magazine into the
Autoloader. Check to ensure correct cartridge orientation.
Good
Cartridge Orientation
Magazine Cartridge Number
Bad
15
Chapter 2 Operation
