Mounting Holes

TSL-A500C
26
Chapter 2 Operation
1.87
[47.5mm]
0.20
[5.0mm]
1.87
[47.5mm]
1.87
[47.5mm]
[58.5mm]
Note:
Maximum mounting screw thread length is 3.0 mm. Longer thread length
may damage the drive.
3.12
[79.25mm]
2–M3
9.00
[228.6mm]
2–M3
3.12
[79.25mm]
3.12
[79.25mm]
2.30 3.12
[79.25mm]
8–M3
