Figure 4. Align the connectors on the enclosure and the LCD panel
Connector on
the enclosure
2. Insert the two screws that you removed in step 1 through the holes in the left
bracket and into the threaded holes in the LCD panel, as shown in Figure 5.
Tighten the screws to secure the LCD panel to the bracket.
Figure 5. Attaching the LCD panel to the VessRAID enclosure
The LCD screen activates when the VessRAID boots. See "Task 7: Connecting
the Power" on page 15.
Go to "Task 3: Mounting VessRAID in a Rack" on page 7.
Task 2: Installing the LCD Panel (Optional)
Connector on
the LCD panel
6
