Specification
Spec Point Current
Short Circuit Current
25A Earth Bond Test
Meter reading range:
Pass Band Limits:
Open Circuit Voltage:
Spec Point Current:
Short Circuit Current
Insulation Test
Meter reading range:
Pass Band limit:
Open Circuit Voltage:
Spec Point Voltage
Short Circuit Current:
Temperature Range
Operating:
Storage:
16
manuals search engine
10A into 100 mΩ at 240 V. 8,7 A into 100 mΩ at 230 V.
Typically 12 A
0 to 1990 mΩ
Range Resolution
0 to 999 mΩ 1 mΩ
900-1990 mΩ 10 mΩ
100 and 500 mΩ
Typically 6 V rms a.c. 50 Hz
Typically 25A into 100 mΩ (10A into 500 mΩ)
Typically 36.5 A
0-99 MΩ
Range Resolution
0 to 10 MΩ 0,1 MΩ
10MΩ to 20 MΩ 0,2 MΩ
20MΩ to 50 MΩ 0,5 MΩ
50MΩ to 99 MΩ 1 MΩ
2 MΩ (Class I) – 7 MΩ (Class II)
≤ 600 V d.c.
≥ 500 V d.c. into 0.5 MΩ
< 2 mA
General
5 ˚C to +40˚ C
-25˚C to +65˚ C
Accuracy
2,5% of reading ±5 mΩ
2,5% of reading ±10 mΩ
Accuracy
2,5% of reading ± 0,1 MΩ
5% of reading ± 0,2 MΩ
5% of reading ± 0,5 MΩ
Indication only
