Product Features

The numbering of the product features shown refers to the
illustration of the measuring tool on the graphic page.
1 Illuminated ring
2 Marking hole
3 Display
4 "ZOOM" button
5 Wood-detection button
6 Metal-detection button
7 "on/off" button
8 Felt pads
9 Sensor area
10 Battery lid
11 Pencil for marking (removable)
12 Latch of battery lid
Display Elements
a "Live" wire indicator
b Wood detection indicator
c Metal detection indicator
d "ZOOM" function indicator
e "ZOOM" measuring indicator
f Measuring indicator
g "AutoCal" calibration indicator
h Indicator for magnetic metals
i Indicator for non-magnetic metals
j Switched-off audio signal indicator
k Battery low indicator
The accessories illustrated or described are not included as standard
delivery.
