30
FX SEND
FX sends enable you to feed signals via a variable control from one or more channels and sum these signals
to the FX bus.
31
FX TO MAIN
The FX TO MAIN control feeds the effects signal into the main mix.
32
PROGRAM
The PROGRAM control has two functions: by turning the PROGRAM control, you choose the number of an
effect. The number of the preset you just chose up blinks in the display. To confirm your selection, press the
PROGRAM control and the blinking stops.
33
DISPLAY
The display shows the effect program number and contains a signal and clip LED. The SIGNAL LED on the
effects module shows the presence of a signal whose level is high enough. This LED should always be on.
However, make sure that the CLIP LED lights up only sporadically. If it is on constantly, you are overdriving
the effects processor, which leads to unpleasant distortion. If this occurs, turn the FX SEND control down a bit.
CONTROL ELEMENTS:
15
