CONTROL ELEMENTS:
7
CLIP
The CLIP LED´s of the mono channels illuminate when the input signal is driven too high, which could cause
distortion. If this happens, use the TRIM control to reduce the preamp level until the LED does not light
anymore.
8
LINE IN
Each stereo channel has two balanced line level input on 6.3 mm Jack connectors for left and right channels.
If only the connector marked "L"(left) is used, the channel operates in mono. Stereo channels are designed to
handle typical line level signals. Both inputs will also accept unbalanced connectors.
9
BAL
The Balance control determines the levels of left and right input signals relative to each other before both
signal are then routed to the main stereo mix bus. If a channel is operated in mono via the line input, the
control has the same function as the PAN control used in the mono channels.
10
LEVEL
The LEVEL control determines the level of the channel signal in the main mix
11
MAIN OUT
The MAIN OUT connectors are unbalanced mono connectors.
12
CD / TAPE
INPUT
The CD/MP3/TAPE INPUTS are used to bring an external signal source (e.g. CD player, tape deck, etc.) into
the console. They can also be used as a standard stereo line input, so the output of a second LAX Mixer.
OUTPUT
These RCA connectors are wired parallel with the MAIN OUT. Connect the inputs of a computer sound card or
a recorder here. The output signal level is setup using the highly accurate MAIN MIX fader.
13
PHONES
6.3 mm stereo jack for headphones.
14
PHONES LEVEL
CONTROL ROOM LEVEL (EXCEPT LAX 502)
Use the PHONES / CONTROL ROOM level to adjust the signal level of the PHONES / CONTROL ROOM output.
15
MAIN MIX LEVEL
Use the MAIN MIX level control to adjust the signal level of the MAIN MIX outputs.
16
PHANTOM POWER
Phantom power is required to operate condenser microphones and is activated using the PHANTOM POWER
switch. (only available for XLR-Mic input)
