Printing Measurement Data

Saving after the measurement result, it is possible to print the datas. For this, the Amprobe
Protocol Printer and the Interface Adapter are required (option).
Selection can be made whether the last saved result, all results, or part of the results should
be printed.
To print the measurement data, please proceed as follows:
1) Perform the desired measurements and save these measurements by pressing the key
"Store" (17), please refer to section "Storing Data".
2) Remove holster
3) Apply the TELARIS Interface Adapter onto the 0100 PLUS.
4) Connect the serial connection cable with the protocol printer.
5) Switch on the printer and set the interface parameter on the protocol printer in
compliance with the 0100 PLUS .
6) To print the last saved result, briefly press the "Print" key (31). "Prt" is displayed on
the screen, the data is transmitted to the protocol printer.
7) To print all memorised data, press the "Print" key (31) for a longer time (approx. 3
seconds). "Prt" is displayed on the screen, The data is transmitted to the protocol
printer.
Now, all data is printed starting from the last memorised result. During printing, the
currently printed memory address number is displayed
• It is important to observe the interface settings of the protocol printer and accordingly set
the interface parameter of the 0100 PLUS (9600 Baud, even parity, 8 data bit, 1 stop bit, 1
start bit, please refer to the technical data section). Please refer to the instruction manual
supplied with the protocol printer (Cat. No. 1196) for printer parameter setting.
