Model and Type Designation

The type shield sticker is located on the rear of the instrument. It contains the instrument
serial number and product designation. When questions arise regarding the instrument,
please always quote product designation and serial number.

Product description

The Amprobe 0100 PLUS is a handy test and measurement instrument for testing in systems
and installations in compliance with DIN VDE. All values required for FAT (Final Approval Test)
reports (e.g. ZVEH) can be measured by using the 0100 PLUS. Reporting, filing or further
processing of measured values is ensured by means of an internal data memory and built-in
infrared interface (for data transfer to PC).

The Amprobe 0100 PLUS is characterised by the following features:

• Measurement of loop resistance and prospective short circuit current measurement without
tripping the RCD
• Line resistance measurement up to 440 V
• Prospective short circuit current measurement
• RCD measurements (contact voltage, trip time, trip current - ramp method)
• Low Ohm measurement
• Insulation measurement with 100, 250 500 V
• Voltage and frequency measurement
• Rotary field test
• Integrated socket test with contact electrode to enable the user to quickly establish
incorrectly installed sockets and/or protective conductor failures
• Integrated memory for approx. 500 measurement values
• Standard, built-in IR RS-232 interface for transferring measurement data to the PC
• Clear and large LCD providing the user with an optimum visual indication of both test values
and limits
• Auto power off

Scope of Supply

1 pc. Amprobe 0100 PLUS
1 Three-pole test lead with safety plug
3 pcs. Measurement leads
3 pcs Croccodile clamps
3 pcs Test probe
1 pc Protective Holster
1 pc Carrying Case
6 pcs Battery 1.5V, type IEC LR6 (Size AA)
1 pc Instruction manual
