Display and Control Elements
Display
1)
Attention, warning symbol
2)
AC voltage / DC voltage
3)
Exceeding the threshold
4)
Exceeding the Contact voltage threshold
5)
External voltage / extraneous voltage present
6)
Socket error
7)
Turn socket by 180°
8)
Battery status indication
9)
Unit indication
10)
Selective RCD has been chosen
11)
Contact voltage threshold
12)
Measurement value indication, large resultfield
13)
Unit indication, small resultfield
14)
Measurement value indication, small resultfield
15)
Current factor display for IΔN when performing RCD checks
16)
Small result field shows pre-selected IΔN when performing RCD checks
17)
Symbol for memory entry
18)
Symbol for compensating test lead resistance
19)
Ramp function (trip current)
20)
Exceeding temperature limit, instrument overheating
1
20
19
18
17
2
3
4
16 15
14
5
6
180°
13
12
10
7
8
9
10
11
