Acoustic Signals
Confirmation Signal:
The confirmation signal is a short beep which is audible once an important procedure is
started (e.g. start of measurement, data memorisation or deleting)
Error Signal:
The error signal is a sequence of two short beep sounds. It indicates either errors occurring
during the measurement or that the selected function may not be carried out.

Carrying out Measurements

• FAT (Final Approval Test) measurements have to be carried out in compliance with the
appropriate applicable standards.

Voltage Measurement

• Never apply voltages exceeding 440V AC/DC to input sockets.
• The instrument is equipped with an integrated internal over voltage protection up to
maximum 500 V AC/DC.
• When switching on or changing to UAC/DC, f measurement range, „AC" is automatically
selected.
• AC voltage is displayed in the large result field (12), frequency in the small result field (14).
• If voltage exceeds 440V, „>440V" is displayed in the large result field. Should this occur
disconnect the test instrument from the EUT immediately.
• If the frequency value is outside the range „---„ is displayed in the small result- field. This
indication is also displayed on the screen if the AC voltage is extremely low.
• Measurement results may be stored by pressing the „Store" (27) key.
WARNING
WARNING
12
