The Polar Speed Sensor is designed to measure speed
and distance when cycling. No other use is intended or
implied. It is compatible with the Polar S510, Polar S710,
Polar XTrainer Plus and Polar Protrainer XT heart rate monitors.
INSTALLING THE POLAR BIKE MOUNT
1. Remove the cover paper from the rubber pad and
attach the pad to the handle bar.
2. Position the wristwatch receiver mounting part forward
(horizontal handlebar) or inside (vertical handlebar).
Pass the cable ties around the handlebar and through
the cable tie holes. Secure the bike mount firmly. Cut
off any excess cable tie ends.
3. Place the wristwatch receiver on the mounting part.
4. Attach the receiver by securing the wrist strap.
INSTALLING THE POLAR SPEED SENSOR
Polar Bike Mount and the wristwatch receiver
A
Polar Speed Sensor
B
C Spoke magnet
Note: There are two spoke magnet options included in
the package (see illustrations 10.1. and 10.2.). You only
need to install one of them.
5. Check the front side of the front fork to find a suitable
place for the speed sensor. The sensor should be
attached 20-50 cm / 8"-1'8" from the mounted
wristwatch receiver.
6. Before attaching the rubber pad, the area underneath
it should be cleaned and dried thoroughly. Remove
the cover paper from the rubber pad and attach it to
the fork.
7. Make sure that the sensor is at 90 degrees to the front
tyre. Check the position of the sensor as shown in the
illustration; viewed from above.
English
8. Adjust the angle of the sensor as shown in the illustration;
viewed from the front.
9. Position the sensor on the rubber pad. Pass the cable
ties through the sensor holes and loosely adjust the
ties. Do not tighten fully yet. If the cable ties are too
short for your bicycle, put two of them together to make
them longer.
10. 1 . Attach the magnet by rotating it around the spoke
before putting the metal cover on the magnet. Install
the magnet at the same level as the sensor. The magnet
must be facing the speed sensor.
or
1 0.2. Attach the screw magnet to a spoke at the same level as
the sensor. The magnet must be facing the speed sensor.
1 1. Fine-tune the positioning of both the magnet and the
sensor so that the magnet passes the sensor closely
but does not touch it. The maximum distance between
the speed sensor and the spoke magnet should be
5 mm / 0,2". Once positioned correctly, tighten the cable
ties securely and cut off any excess cable tie ends.
Your safety is important to us. Check that you can turn
your handlebar normally and cable wires for brakes or
gearing do not catch on the sensor. Check also that
the sensor does not disturb pedaling or the use of
brakes or gearing. While riding your bike, please keep
your eyes on the road to prevent possible accidents
and injury.
OPERATION OF THE SPEED SENSOR
• You may test the operation of the speed sensor by
checking that the sensor gives out an orange flash
when the magnet passes the sensor. Note that the
orange flash is only a checking procedure and the
flashing does not continue after 50 flashes when cycling.
If you would like to check this procedure again, you
must have a pause of 3 minutes during which time the
magnet may not pass the speed sensor.
• Before you start cycling, you should wait for the heart rate
code to be recognised by the wristwatch receiver. The
heart rate code search lasts max. 15 seconds with Polar
S510 and Polar S710, max. 20 seconds with Polar Protrainer
XT and max. 30 seconds with Polar XTrainer Plus.
• For more instructions on how to use the Polar Speed
Sensor, please refer to the user's manual of the heart
rate monitor in question.
FREQUENTLY ASKED QUESTIONS
What should I do if...
...the speed reading is 00 or there is
no speed reading while cycling?
• Check the correct position of the speed sensor with
the spoke magnet and the wristwatch receiver.
• Check that you have set correct cycling settings in
your wristwatch receiver.
• If the 00 reading appears irregularly, this may be due
to temporary electromagnetic interference in your
current surroundings.
• If the 00 reading is constant, you may have exceeded
2500 riding hours and the battery needs to be replaced.
...there are irregular speed, distance or
heart rate readings?
• Electromagnetic interference as well as interference
from other wireless cycle computers may affect readings
of speed, distance and heart rate.
• Disturbances may occur near high voltage power lines,
traffic lights, overhead railway cables, electric bus lines
or trams, televisions, car motors, some motor driven
exercise equipment or cellular phones.
• To avoid crosstalk from another cyclist with a Polar
Speed Sensor, keep a distance of at least 1 metre /
3'4" between your wristwatch receiver and the Polar
Speed Sensor of the other cyclist.
TECHNICAL SPECIFICATION
Operating temperature –10 °C to +60 °C / 14 °F to 140 °F
Battery type: CR 2032
Battery life: average 2500 hours of use
Accuracy: ±1 %
Water-resistant
CARE AND MAINTENANCE
• Do not immerse the speed sensor in water.
• Avoid hard hits as these may damage the sensor.
Battery replacement
We highly recommend you send the speed sensor to an
authorised Polar Service Centre for battery replacement,
where the unit is water-resistant tested after the battery
has been replaced. Water resistance cannot be guaranteed
after an unauthorised service. However, if you prefer
changing the battery yourself, please follow these instructions
carefully:
Detach the sensor from your bicycle.
1. Open the sensor by removing the two small screws,
counter-clockwise, with a small screwdriver.
2. Lift the case off carefully. Hold the sensor cover upwards
so that the PCBA (printed circuit board assembled)
stays in the cover.
3. Remove the PCBA carefully.
4. Press the battery cover gently. Release a hook of the
cover from the opposite side of the PCBA and lift it
upwards. Remove the old battery.
5. Insert a new battery with the plus (+) side facing up
and press the battery cover gently so that it is attached
to the PCBA at all corners.
6. Put the PCBA back into place.
7. Check that the sealing ring stays in its groove. Replace
the case and tighten the screws.
8. Test the sensor by checking that it gives out an orange
flash when the spoke magnet passes the speed sensor.
9. Do not throw the replaced battery away with normal
waste; take it to a place where problem waste is handled.

WARRANTY

• Polar Electro Oy warrants to the original consumer/
purchaser of this speed sensor that the product will be
free from defects in material or workmanship for one
year from the date of purchase. Please keep the receipt,
which is your proof of purchase!
• Warranty does not cover sensor battery, damage due
to misuse, abuse, accidents or non-compliance with
precautions; improper maintenance, commercial use,
cracked or broken cases.
• Warranty does not cover damage or consequential
damage caused by service not authorised by Polar
Electro Oy.
• During the warranty period the product will be either
repaired or replaced at an authorised service centre
free of charge.
• This warranty does not affect the consumer's statutory
rights under applicable national or state laws in force,
or the consumer's rights against the dealer arising from
their sales/purchase contract.
