Activate the standalone mode:
The standalone mode is activated in the menu: DMX/STANDALONE
independent if it was programmed manually or by a connected DMX board.
To enter menu DMX/STANDALONE press key MENU and afterwards key + three times.
You will find D MX/STANDALONE displayed.
To confirm press Enter.
Select standalone-function by pressing key + and press ENTER one time to activate.
S-ALONE: 1 / 2 will be shown on the display
Deactivate the standalone mode:
To deactivate standalone mode press ENTER and key - one time.
The display will show:
Press key ENTER again and find
Leave menu by pressing key MENU

3.5 Lamp control and lamp ignition

There are differnt modes for lamp ignition and lamp control available.:
Lamp ignition configuration is set in the fixtures personality configuration in Menu
MODE
possibility no.1: The lamp ignites as soon as the fixture powers up
possibility no 2: The lamp ignites as soon as the fixture powers up and a DMX value
possibility no 3: The lamp ignites so soon as the fixture powers up and any DMX signal is
Configuration of lamp control:
The lamp control configuration is independent to the lamp ignition mode.
The lamp control is based on DMX values. It is used to switch off the lamp by means of the
control console.
To enable the lamp control mode enter personality configuration of the fixture.
Activate menu LAMP ON/OFF DMX
If the option OFF
(switched off) by DMX if possibility no. 2 is selected.
If the option ON is selected in
before and it can always be controlled (switched off) by DMX if there is a DMX value send
between 232-239 on channel no. 5 for more than 3 seconds.
DMX MODE
DMX/STANDALONE.
between 248 - 255 is send on channel no. 5
connected to the fixture.
is selected in LAMP ON/OFF DMX
LAMP ON/OFF DMX menu,
displayed
(AUTO DMX)
menu, the lamp can only be controlled
the lamp will ignite like discribed
LAMP
(AUTO START)
(AUTO OFF)
