1. ON / OFF switch
2. Water tank
3. Cups warmer
4. Pump pressure gauge
5. Boiler manometer
6. Hot water handle
7. Steam handle
8. Grill tray
9. Hot water jet
10. Steam jet
11. Endowment group
12. Filter holder
13. Drip tray
14. Light ON / OFF indicator and low water in the tank when
flashing
15. Lever group endowment
MODEL
Voltage
Frequency
Power
Capacità
serbatoio acqua
Capacità caldaia
Dimensions
(LxWxD) mm.
Weight (Kg.)
PRO 6.1
120V 230-240V
60Hz 50Hz
1520W
2.9 Lt
1,8 Lt
300x410x425
28
116. Brush for cleaning the brew group
17. Pipe connection to the water network
18. Tamper
19. Coffee measure
20. 1 cup filter 7 gr.
21. 2 cups filter 16 gr.
22. One cup filter holder
23. Two cup filter holder
24. Closed filter
25. Silicone hose to drain water
26. Manometer BPPC (Brewing Pressure Profiling Control)
PRO 5.1
120V 230-240V
60Hz 50Hz
1520W
2.9 Lt
1,8 Lt
300x395x425
23
21
PRO 3.1
120V 230-240V
60Hz 50Hz
1520W
2.9 Lt
1,8 Lt
300x395x425
23
