General Notes - Scheppach Ox 3-1200 Originalanleitung

Manufacturer
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Germany
Dear customer
We hope you have a lot of fun and success using
your new machine.
Note:
Under current product liability regulations, the manu-
facturer of this equipment will not be liable for dam-
ages to the equipment or caused by it in the case of:
• improper handling,
• failure to observe the operating instructions,
• repairs by third parties, non-authorised technicians,
• installation of and replacement by non-original
spare parts,
• non-intended use,
• failures of the electrical system while not adhering
to the electrical regulations and regulations of the
VDE (German Association for Electrical, Electronic
and Information Technologies) 0100, DIN 57113 /
VDE0113.
Our recommendations:
Read the entire text of the operating instructions be-
fore installation and operation.
These operating instructions are to help you to get
to know your machine and its intended fields of ap-
plication.
The operating instructions contain important notes
on how to work safely, properly, and efficiently with
the machine and how to avoid hazards, save costs of
repairs, keep downtimes short improve reliability and
product life of the machine.
In addition to the safety instructions in this manual,
you must observe all regulations of your country ap-
plicable for the operation of the machine.
Keep the operating instructions close to the ma-
chine, protected by a plastic envelope against dirt
and humidity. Any operator must read the operating
instructions prior to work and follow them precisely.
Only people trained to operate the machine and who
are aware of the associated dangers are permitted
to work with the machine. The required minimum age
must be observed.

General Notes

• After unpacking, inspect all parts for possible trans-
port damages. In the case of complaints you must
inform the deliverer immediately. Subsequent com-
plaints will not be accepted.
• Check the shipment to ensure that it is complete.
• Familiarise yourself with the equipment with the
help of the operating instructions before putting
the equipment into operation.
• Use only original parts as accessories and spare
parts. You can buy spare parts from your special-
ist dealer.
12 english
• When you order, please state our order numbers
as well as the equipment's type and year of manu-
facture.
Scope of Delivery
Operating instructions
Specifications
Dimensions
D/W/H
Table height mm
working height
mm
log length max cm
power max. t*
cylinder travel cm
forward speed
cm/s
return speed cm/s
oil volume l
weight kg
Noise level at idle
dB(A)
Drive
Motor
input power P1
kW
output power P2
kW
duty type
motor speed 1/
min
motor protection
phase inverter
Specifications are subject to change!
* The maximum achievable splitting force is dependent on the
resistance of the splitting material.
Warning Symbols / Warnings
Please read the manual before start-up
Wear safety footwear
Wear work gloves
Use hearing protection and safety goggles
Wear a hardhat
Authorised personnel only
No smoking in the working area
Do not spill hydraulic oil on the floor
Keep your workspace clean! Untidiness can
cause accidents!
If a crane is used, put the lifting belt round the
housing. Never lift the firewood splitter by the
hand grip,
Ox 3–1200
Hydraulic log splitter
830 x 540 x 1560
50/430/810
930
600/965/1040/1330
12
53
4
20
9,0
199
88
400 V/50 Hz
4,10
3,30
S6/40 %
1420
yes
yes
