SIW 6MU - SIW 11MU
6.11 Electrical pipe heater (2nd heat generator)
7 Complies with the European safety regulations
8 Additional model features
8.1 Water in device is protected against freezing
8.2 Max. operating overpressure (heat source/heat sink)
9 Domestic hot water cylinders
Material in accordance
9.1 nominal volumen
9.2 Heat exchanger area
9.3 Heat loss at 50°C cylinder temperature
20°C room temperature
9.4 Draw-off rate (without re-heating)
3
10 Heat output / COP
1. The specified sound pressure level corresponds to the operating noise of the heat pump in heating operation with a flow temperature of 35 °C.
The specified sound pressure level represents the free sound area level. The measured value can deviate by up to 16 dB(A), depending on the installation location.
2. Please note that additional space is required for pipe connections, operation and maintenance.
3. These data indicate the size and capacity of the system according to EN 14511. For an analysis of the economic and energy efficiency of the system, the bivalence point and
regulation should be taken into consideration. These specifications can only be achieved with clean heat exchangers. Information on maintenance, commissioning and operation
can be found in the respective sections of the installation and operating instructions. The specified values have the following meaning, e.g. A7 / W35: Heat source temperature
7 °C and heating water flow temperature 35 °C.
4. See CE declaration of conformity
5. The heat circulating pump and the heat pump manager must always be ready for operation.
6. Mixed water withdrawal temperature 38 °C and cylinder temperature 45 °C.
EN-14
kW
5
bar
in litres
m²
kW/h24h
6
Litres
at B-5 / W45 kW / ---
at B0 / W55 kW / ---
at B0 / W45 kW / ---
at B0 / W35 kW / ---
452236.66.02 · FD 9303
2 or 4 2 or 4
4 4
Yes Yes
3,0 3,0
EN 1.4162 EN 1.4162
170 170
2,2 2,2
0,86 0,86
207 207
EN 14511 EN 14511
4,7 / 3,1 6,3 / 3,2
5,2 / 2,9 6,8 / 2,7
5,5 / 3,6 7,2 / 3,6
5,8 / 4,8 7,6 / 4,7
2 or 4
4
Yes
3,0
EN 1.4162
170
2,2
0,86
207
EN 14511
8,6 / 3,2
9,5 / 3,0
9,8 / 3,6
10,3 / 4,6
