5.3 Removing the heat pump module

Removing the heat pump module enables to heat pump to be
transported easily in a horizontal position and the heat pump
module to be transported separately.
5.
3x
3.
2x
1.
6. 4.
ATTENTION!
In installed and dismantled state, the heat pump module may only be
tilted by a maximum of 45° (in each direction).
www.dimplex.de
After transportation, the transport fastening on the heat pump
module is to be removed from both sides.
ATTENTION!
Before start-up, the transport fastening must be removed.
452236.66.02 · FD 9303
SIW 6MU - SIW 11MU
EN-7
