Replacing the fuse
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Open the fuseholder on the rear panel with a fitting screwdriver.
Step 2: Remove the old fuse from the fuseholder.
Step 3: Install the new fuse in the fuseholder.
Step 4: Replace the fuseholder in the housing.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
Should you have further questions, please contact your dealer.
TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
DMX control channels:
DMX512 connection:
Sound-control:
Flash-rate:
LED type:
Number of LEDs:
Maximum PAN-movement:
Maximum TILT-movement:
Dimensions (LxWxH):
Weight:
Maximum ambient temperature T
Maximum housing temperature T
Min. distance from flammable surfaces:
Min. distance to lighted object:
Fuse:
Accessory:
EUROLITE TPC-10 Coupler, silver
EUROLITE TPC-10 Coupler, black
EUROLITE Safety bond A 4x1000mm up to 15kg silver
EUROLITE Safety bond A 4x1000mm up to 15kg black
EUROLITE DMX cable XLR 3pin 3m bk
PSSO DMX cable XLR 3pin 3m bk Neutrik
SOMMER CABLE DMX cable XLR 3pin 3m bk Hicon
SOMMER CABLE DMX cable XLR 3pin 3m bk Neutrik
EUROLITE Omega Holder 9
Please note: Every information is subject to change without prior notice. 03.05.2016 ©
:
a
(steady state):
C
35/35
100-240 V AC, 50/60 Hz ~
120 W
13/44
3-pin XLR
via built-in microphone
10 Hz
10 W QCL, RGBW
9
unlimited
100°
479 x 429 x 208 mm
8.5 kg
45° C
50° C
0.5 m
0.1 m
T 3 A, 250 V
No. 59006856
No. 59006858
No. 58010320
No. 58010344
No. 3022785H
No. 30227810
No. 30307457
No. 3030746Z
No. 51786522
00099571.DOC, Version 1.0
