Components that can be taught-in

Syn Attempts to synchro-
nize with known HM
device
CRC CRC error after firm-
ware update
FUP Firmware update is
in progress
tSd Temperature sensor
value defect or out
of range
trd Transceiver module
defect
19 Components that can be taught-
in
The following HomeMatic devices can be taught-in the the
room thermostat:
• max, 1 HomeMatic Central Control Unit (CCU or con-
figuration adapter)
• max. 8 HomeMatic Radiator Thermostats
• max. 8 HomeMatic Door/Window Contact / Window Ro-
tary Handle Sensors
• max. 8 button pairs of HomeMatic Remote Controls or
Display Push-Buttons
• max. 8 HomeMatic Switching Actuators (8 channels)
If you have taught-in the HomeMatic Room
Thermostat to a radiator thermostat, the open-win-
dow detection will be deactivated automatically via
the temperature fall detection of the radiator
thermostat.
78
/
Please perform firmware
update again
/
replace device or operate
device in current tempera-
ture range
Replace device

20 Technical specifications

Device short description:
Supply voltage:
Battery lifetime:
Current consumption:
Degree of protection:
Protection class:
Ambient temperature:
Dimensions (W x H x D)
without frame
incl. frame:
Weight:
Radio frequency:
Receiver class:
Typ. open area RF range:
Duty cycle:
Method of operation:
Subject to technical changes.

Instructions for disposal:

Do not dispose of the device with regular domestic
waste. Electronic equipment must be disposed of
at local collection points for waste electronic
equipment in compliance with the Waste Electrical
and Electronic Equipment Directive.
The CE sign is a free trading sign addressed
exclusively to the authorities and does not include
any warranty of any properties.
Technical specifications
HM-TC-IT-WM-W-EU
2 x 1.5 V LR03/micro/AAA
approx. 1 year
40 mA (max.)
IP20
III
0 to 50 °C
55 x 55 x 20 mm
86 x 86 x 21.5 mm
74 g (not incl. batteries)
868.3 MHz
SRD Class 2
> 100 m
< 1 % per h
Type 1
