Error Messages

When you turn on the fixture, it will make a reset first. The display may show "Xerr" while there are
problems with one or more channels. "X" stands for channel 4, 5, 6, 7, 8 equipped with a testing
sensor for positioning.
For example, when the display shows "4Err", it means there is some error in channel 4. If there are
some errors on channel 4, channel 5, channel 6 at the same time, you may see the error message
"4Err", "5Err","6Err" flash repeatly for 5 times, and then the fixture will generate a reset signal, all the
stepper motors will reset. If the error messages maintain after performing reset more than 3 times, it
will detect whether the fixture has more than 3 errors. If the fixture has more than 3 errors (including
3 errors), all the channels can not work properly; but if the fixture has less than 3 errors, only the
channels which have errors can not work properly, others can work as usual.
4Err:
(Color-wheel error) This message will appear after the reset of the fixture if the magnetic-indexing circuit
malfunctions (sensor failed or magnet missing) or the stepping-motor is defective (or its drive circuit on the
main PCB). The color wheel is not located in the default position after the reset.
5Err:
(Static gobo-wheel error) This message will appear after the reset of the ficture if the magnetic-indexing
circuit malfunctions (sensor failed or magnet missing) or the stepping-motor is defective (or its drive circuit on
the main PCB). The static gobo-wheel is not located in the default position after the reset.
6Err:
(Rotating gobo-wheel error ) This message will appear after the reset of the fixture if the magnetic-indexing
circuit malfunctions(sensor failed or magnet missing) or the stepping-motor is defective (or its drive circuit on
the main PCB). The rotating gobo-wheel is not located in the default position after the reset.
7Err:
(Rotating gobo indexing error) This message will appear after the reset of the fixture and if the magnetic-
indexing circuit malfunctions (sensor failed or magnet missing) or the stepping-motor is defective (or its driver
circuit on the main PCB). The rotating gobo is not located in the default position after the reset.
8Err:
(Effect-wheel error) This message will appear after the reset of the fixture and if the magnetic-indexing circuit
malfunctions (sensor failed or magnet missing) or the stepping-motor is defective (or its driver circuit on the
main PCB). The effect-wheel is not located in the default position after the reset.

CLEANING AND MAINTENANCE

The operator has to make sure that safety-relating and machine-technical installations are inspected by an
expert after every four years in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are inspected by a
skilled person once a year.
The following points have to be considered during the inspection:
1) All screws used for installing the devices or parts of the device have to be tighly connected and must not
be corroded.
2) There must not be any deformations on housings, fixations and installation spots (ceiling, suspension,
trussing).
3) Mechanically moved parts like axles, eyes and others must not show any traces of wearing (e.g. material
abrading or damages) and must not rotate with unbalances.
4) The electric power supply cables must not show any damages, material fatigue (e.g. porous cables) or
sediments. Further instructions depending on the installation spot and usage have to be adhered by a
skilled installer and any safety problems have to be removed.
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
