OPERATION

After you connected the effect to the mains, the PSC-575 starts running. During the Reset, the motors are
trimmed and the device is ready for use afterwards.

Stand Alone operation

In the Stand Alone mode, the PSC-575 can be used without controller.
Disconnect the PSC-575 from the controller and call the internal program.
1. Press [ENTER] for 3 seconds to enter the main menu "MODE" (display flashing)
2. Press [ENTER] and select "RUN" by pressing [UP] button.
3. Press [ENTER] and select "AUTO" by pressing [UP] button.
4. Press [ENTER] and select "ALONE" by pressing [UP] button.
5. Press [ENTER] to confirm, the display shows "AU-A".
6. Press [EXIT/DN] in order to return to the main menu.
Please refer to the instructions under Control Board, Main functions, menus Run and Edit.

DMX-controlled operation

You can control the projectors individually via your DMX-controller. Every DMX-channel has a different
occupation with different features. The individual channels and their features are listed under DMX-protocol.

Addressing

The Control Board allows you to assign the DMX starting address, which is defined as the first channel from
which the PSC-575 will respond to the controller.
If you set, for example, the address to channel 16, the PSC-575 will use the channel 16 to 29 for control.
Please, be sure that you don't have any overlapping channels in order to control each PSC-575 correctly and
independently from any other fixture on the DMX-chain.
If several PSC-575 are addressed similarly, they will work synchronically.
Press the Up/Down-buttons for setting the desired starting address. Now you can start operating the PSC-
575 via your lighting controller.
Note:
After switching on, the PSC-575 will automatically detect whether DMX 512 data is received or not. If the
data is received, the the display will show "A.001" with the actually set address. If there is no data received
at the DMX-input, the display will show "A001" with the actually set address.
This situation can occur if:
- the 3 PIN XLR plug (cable with DMX signal from controller) is not connected with the input of the PSC-575.
- the controller is switched off or defective, if the cable or connector is defective or the signal wires are swap
in the input connector.
Note:
It's necessary to insert the XLR termination plug (with 120 Ohm) in the last lighting in the link in order to
ensure proper transmission on the DMX data link.

DMX-protocol

Control channel 1 - Horizontal movement (Pan)
Push slider up in order to move the mirror horizontally (PAN).
Gradual mirror adjustment from one end of the slider to the other (0-255, 128-center). The mirror can be
stopped at any position you wish.
DMX-value Feature
0-255 Gradual adjustment of the mirror position from left to right
34/91 51839965X17NXS_V_1_0.DOC
