Only operate the fixture after having checked that the housing is firmly closed and all screws are tightly
fastened.
The lamp must never be ignited if the objective-lens or any housing-cover is open, as discharge lamps may
explose and emit a high ultraviolet radiation, which may cause burns.
The maximum ambient temperature t = 45° C must never be exceeded.
a
Operate the device only after having become familiar with its functions. Do not permit operation by persons
not qualified for operating the device. Most damages are the result of unprofessional operation!
Please use the original packaging if the device is to be transported.
Please consider that unauthorized modifications on the device are forbidden due to safety reasons!
Never remove the serial barcode from the device as this would make the guarantee void.
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, lamp explosion, crash etc.

DESCRIPTION OF THE DEVICE

Features

Professional scanner with Iris
DMX-controlled operation or stand alone operation with Master/Slave-function • Sound-controlled via built-in
microphone • 48 preprogrammed scenes in Program Run for stand alone operation • Number of scenes in
Program Run can be changed individually • The scenes in Program Run can be modified via the Control
Board or via an external controller and loaded into the memory • 8 brilliant, dichroic colours plus white •
Switchable colour change (mode 1: only full colours, mode 2: colour-change at every position) • Rainbow-
effect with adjustable speed in both directions • Gobo-wheel 1 with 6 rotating gobos plus open • All gobos
can be interchanged • Gobo-wheel 2 with 7 static metal gobos plus open • With gobo-shake function • Effect-
wheel with rotating 3-facet prism, correction-filters 3,200 K and 5,600 K, UV-filter, Frost-filter • Macro-function
for rotating gobos/rotating prism combinations • Motorized focus • Steplessly adjustable iris • Strobe-effect
with 1-13 flashes per second via shutter • Mechanic dimmer • Exact positioning via 16 bit Pan/Tilt movement
resolution • Control-Board with 4-digit display and foil-keyboard for adjusting the DMX-starting address,
Pan/Tilt-Reverse, Program, Reset, lamp on/off, operating hours • For extremely bright 575 W HMI-lamp •
DMX-control via every standard DMX-controller
