Procedure:
The ODD Outdoor Dome should be installed outside areas where persons may walk by or be seated.
IMPORTANT! OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, including (but not limited to)
calculating working load limits, installation material being used, and periodic safety inspection of all
installation material and the ODD Outdoor Dome. If you lack these qualifications, do not attempt the
installation yourself, but instead use a professional structural rigger. Improper installation can result in bodily
injury and.or damage to property.
The device has to be installed out of the reach of people.
If the ODD Outdoor Dome shall be lowered from the ceiling or high joists, professional trussing systems have
to be used. The ODD Outdoor Dome must never be fixed swinging freely in the room.
Caution: Devices may cause severe injuries when crashing down! If you have doubts concerning the safety
of a possible installation, do NOT install the ODD Outdoor Dome!
Before rigging make sure that the installation area can hold a minimum point load of 10 times the ODD
Outdoor Domes weight.
CAUTION!
Use 2 appropriate clamps to rig the device on the truss.
Follow the instructions mentioned at the bottom of the base.
Make sure that the device is fixed properly! Ensure that
the structure (truss) to which you are attaching the devices is secure.
The ODD Outdoor Dome can either be placed directly on the floor or rigged in the truss.
For overhead use (mounting height >100 cm), always install a safety-rope that can hold at least 12 times the
weight of the complete installation (ODD + fixture). You must only use safety-ropes with quick links with
screw cap.
If you use safety-ropes for up to 60 kg, two safety-ropes need to be used!
Pull the safety-rope through the attachment eyelet and over the trussing system or a safe fixation spot. Insert
the end in the quick link and tighten the fixation screw.
The maximum drop distance must never exceed 20 cm.
A safety rope which already hold the strain of a crash or which is defective must not be used again.
DANGER TO LIFE!
Before taking into operation for the first time, the installation has to be approved by an expert!
Screw one clamp each via a M12 screw and nut onto the Omega-clamps.
Insert the quick-lock fasteners of the first Omega-clamp into the respective holes on the bottom of the
device. Tighten the quick-lock fasteners fully clockwise. Install the second Omega-clamp.
Please note: for overhead installation, the device in the ODD Outdoor Dome must always be installed via
the Omega-clamps or via the mounting-bracket. The device must always be secured via a safety-rope.
Please note: for overhead installation, the venting slots of the fans need to be closed with the air tubes in
order to avoid water entering the device.

Connection with the mains

Connect the device to the mains with the power-plug.
