Technical information

Rating Plate
Made in Germany
© Inter IKEA Systems B.V. 1999
702.228.18
21552
PQM
The graphic above represents the rating
plate of the appliance (without serial num-
ber which is generated dynamically during
the production process), which is located at
its underneath surface of the casing.

Installation

Manufacturer is not responsible for any in-
jury to persons and pets or damage to
property caused by failure to comply fol-
lowing requirements.
Caution! To proceed with the
installation refer to the assembly
instructions.
Warning! Installation process must
follow the laws, ordinances, directives
and standards (electrical safety rules and
regulations, proper recycling in accordance
with the regulations, etc.) in force in the
country of use!
Warning! The appliance must be
earthed!
Warning! Risk of injury from electrical
current.
• The electrical mains terminal is live.
• Make electrical mains terminal free of
voltage.
Model DAGLIG Typ 58 HAD 56 AO 7,1kW
PNC 949 594 312 00 S NO ............... 220V-240V AC 50-60 Hz
Dear Customer, please apply here aside
the sticker you can find in the dedicate
plastic bag inserted inside the hob packag-
ing. This will allow us to assist you better, by
identifying precisely your hob, in case you
will need in future our assistance. Thank you
for your help!
• Loose and inappropriate plug and socket
connections can make the terminal over-
heat.
• Have the clamping connections correctly
installed.
• Use strain relief clamp on cable.
• Follow the connection diagram (it is loca-
ted on the underneath surface of the
casting of the hob).
Important! You must observe the minimum
distances to other appliances and furniture
cabinets or other units according to
Assembly Instruction.
If there is no oven beneath the hob insert a
dividing panel at a minimum distance of 20
mm from the bottom of the hob.
Do not use silicon sealant between the ap-
pliance and the worktop. Avoid installing
the appliance next to doors and under win-
dows as hot cookware may be knocked off
the rings when doors and windows are
opened.
