Screensaver:

9. Technical data

Input
Video/Audio
interfaces
HDBT
Control
I/O inputs
RS232
General
Resolution range
Audio input
34
If a Quickselect unit is activated without any active source being
connected (by pressing the internal or external Show-Me button),
the screensaver of the internal VGA-to-HDMI scaler appears.
The screensaver shows the current installed firmware version of
the individual Quickselect module.
If required in specific cases the screensaver can be deactivated
(or re-activated) by using the RS232 "Send" text field of the GUI
software.
Note: After re-activating the screensaver which has been deactivated
before, the screensaver only becomes active if the video input source
is disconnected and reconnected or if the Quickselect unit is power
cycled.
2 x HDMI (HDMI 1.4 with
HDCP), VGA, audio (3.5 mm)
HDBT-In
One contact input (3-pin.
Phoenix connector) each for:
- HDMI1, HDMI2 and VGA
- ShowMe-function
3-pin. Phoenix connector for
device control
HDMI: up to 4K2K@60 Hz
(4:2:0), HDCP 2.0, incl. 3D
VGA: 800x600, 832x624
(MAC), 1024x768, 1152x864,
1152x870 (MAC), 1280x720,
1280x768, 1280x800,
1280x960, 1280x1024,
1360x768, 1366x768,
1400x1050, 1440x900,
1600x1200, 1680x1050,
1920x1080P, 1920x1200
HDMI: embedded
VGA: 3.5 mm headphone jack
Output
Video/Audio HDMI (HDMI 1.4 with HDCP),
interfaces audio (3.5 mm)
HDBT HDBT-Out
USB socket Type-A, max. 2A
One output (3-pin. Phoenix
connector) each with LED
I/O outputs driver for:
- HDMI1, HDMI2 and VGA
- ShowMe-function
Operating 0°C up to 35°C
temperature
10% up to 90%,
Humidity
non-condensing
Storage
-20°C up to 70°C
temperature
HDMI embedded +
Audio output
3.5 mm headphone jack
