Backing up and loading the configuration of a QuickSelect 3.0 +:
Use the buttons
QuickSelect 3.0 + (red frame) as a file – and also recover it again.
Note: If you back up these settings for your project documentation, you can restore the same settings
again (template&data backup).
Resetting one/all QuickSelect 3.0 + to factory settings:
If a factory reset is desired, also ensure that you return the address BCD switches to 99 (factory condition).
Alternative resetting via button:
1. Push and hold the internal ShowMe button and restore power supply.
2. Keep the button pushed until the LEDs at the device front flash quickly a few times - then release.
3. Wait until the LEDs go out and all LEDs flash after a while (sign for the end of the factory reset).
7

RS232 control

.
The free configuration software or a media control also permits controlling the entire QuickSelect
system via the RS232 connection in all details.
The HDBT-Bus can also transmit RS232-control commands for controlling further devices such as pro-
jectors and display, bidirectionally (pass through). Connect e. g. the RS232-interface of the media control
simply to a RS232-terminal.
The detailed RS232-protocol and a driver for Neets controls can be found online at:
shop.kindermann.de/evp/webshop/navigation_Path/7447000500.html
Enter RS232 commands manually and read out answers:
Display Power Control function:
The Display Power Control feature allows direct automatic power-on/off switching of one or more
displays or projectors upon signal detection, even without using an external AV control system.
To use this function each display device must be connected to an individual Quickselect unit via RS232.
If the last Quickselect of a chain connects to a compatible display device via HDBT Link-out then both,
the RS232 commands and the video signal, can be routed to the display device (only with compatible
devices).
32
to back up the entire current configuration of the selected
This function has a safety prompt to prevent accidental overwriting.
You can use these text fields to send RS232 commands and read the
response of the QuickSelect 3.0+ chain. All values are displayed in HEX.
The commands of the respective control commands are automatically
entered under RS232-TxD (Hex) and may be copied, e. g. for the purpose
of driver creation for media controls. The same applies to the respective
device feedbacks.
Note: ALL commands entered under RS232-TxD are always sent in
sequence. If only a single command is to be sent, please clear the field
first and enter the individual command.
