13 Device information

13.1 LIA 7IM

Model code
Performance Test Condition
Heating Capacity
Heating Capacity / COP in acc.to EN 14511
COP
Noise Level
Air Flow
Refrigeration Control Device
Refrigerant Oil
Refrigerant (R410A)
Dimension
Dimension (Package)
Weight (Unit/Pack)
Pipe Diameter
Standard Length
Pipe Length Range
I/D&O/D Hight Difference
Additional Gas Amount
Refrigeration Charge Less
Compressor
Fan
Heat Exchanger
www.dimplex.de
Item
A7/W35
A2/W35
A-7/W35
A-7/W55
A-15/W35
Height
Width
Depth
Hight
Width
Depth
Liquid
Gas
Type
Motor Type
Rated Output
Type
Material
Motor Type
Rated Output
Fan Speed
Fin material
Fin Type
Row x Stage x FPI
Size (W x H x L)
Unit
kW
BTU/h
kJ/h
kW / ---
kW / ---
kW / ---
kW / ---
kW / ---
W/W
BTU/hW
dB(A) 48 (distance 1,0m, hight 1,5m)
Power Level dB
m³/min
cm³
kg (oz)
mm
mm
mm
mm
mm
mm
kg
mm (inch)
mm (inch)
m (ft)
m (ft)
m (ft)
g/m (oz/ft)
m (ft)
kW
W
rpm
mm
13.1
Outdoor Unit
LIAV 7IM
EUROVENT
7.00
23900
25200
7.00/4.40
6.55/3.30
5.15/2.65
4.80/1.80
4.60/2.30
4.40
15.0
66
45
Expansion Valve
FV50S (PVE) / 900
1,45
795
900
320
912
997
447
66 / 72
6.35 (1/4)
15.88 (5/8)
7 (23.0)
3 (9.8) ~ 30 (98.4)
20 (65.6)
30 (0.3)
10 (32.8)
Rotary
Brushless (4-poles)
1.70
Propeller Fan
PP
Brushless (4-poles)
60
580
Aluminium (Pre Coat)
Corrugated Fin
2 x 30 x 17
19.05 x 762 x 873.8
19.05 x 762 x 903.8
EN-21
