DMX512 Operation

The machine uses one control channel to control the fog output volume. The channel ranges between the
DMX values 0 to 255.
DMX value
0 – 5 No fog output
6 – 249 Minimum fog output (5 %)
High fog output (95 %)
250 – 255 Maximum fog output (100 %)
In the DMX mode, the fog machine cannot be controlled via the remote control.

Wireless Control (Accessory)

With the optional wireless control ZG-1W it is possible to emit fog via radio over a distance of up to 50
meters.
Connect the receiving unit to the 6.3 mm jack REMOTE CONTROL. Slide the transmitter's clip upwards until
it locks. Keep any of the two buttons pressed, to emit fog (continuous operation with 100 % fog volume). The
red control LED lights. As soon as you release the button, the fog output will stop.

Notes Regarding Operation

1
All fog machines develop condensation around the output nozzle. Because this may result in some
moisture accumulation on the surface below the output nozzle, consider this condensation when
installing your unit.
2
All fog machines may sputter small amounts of fog occasionally during operation and for a minute or so
after being turned off.
3
All fog machines have a recycling period after long bursts when the machine will shut itself down for a
short period in order to heat up again. During this time no fog can be produced.
4
If you experience low output, pump noise or no output at all, disconnect from mains immediately. Check
the fluid level, the external fuse, remote control connection and the power supply. If all of the above
appears to be ok, reconnect the unit again. If fog does not come out after holding the MANUAL button
on the remote control for 30 seconds, check the tube attached to the tank to make sure there is fluid
going through it. If you are unable to determine the cause of the problem, do not simply continue
pushing the remote button, as this may damage the unit. Return the machine to your dealer.
