DMX512 Operation

For operation with a controller with DMX512 protocol, the fog machine is equipped with 8 control channels.
To be able to operate the machine with a DMX controller, the DMX starting address must be set for the first
DMX channel. For this, press the button MENU so many times until "Addr" is indicated in the display. Then
press ENTER to make your settings. Use the buttons ▲ and ▼ to set the address between 001 and 512.
Once again, press ENTER to confirm your settings. You may now start operating the machine via your DMX
controller. The section below describes all functions of the 8 control channels.
Channel 1 – Fog output
DMX value
000 – 009
010 – 255
Channel 2 – Brightness red LEDs
DMX value
000 – 009
010 – 255
Channel 3 – Brightness green LEDs
DMX value
000 – 009
010 – 255
Channel 4 – Brightness blue LEDs
DMX value
000 – 009
010 – 255
Channel 5 – Brightness red, green and blue LEDs (color mixing)
DMX-Wert
000 – 009
010 – 255
Channel 6 – Color change speed
DMX value
000 – 009
010 – 255
Channel 7 – Strobe control
DMX value
000 – 009
010 – 255
Channel 8 – Master dimmer
DMX value
000 – 009
010 – 255
www.eurolite.de
Function
off
on
Function
off
Dimming from 1 – 100%
Function
off
Dimming from 1 – 100%
Function
off
Dimming from 1 – 100%
Funktion
off
Dimming from 1 – 100%
Function
off
slow → fast
Function
off
slow → fast
Function
off
Dimming from 1 – 100%
