In case the camera's position is prone to rapid light changes, e.g. changes in sun intensity
due to cloud movements, you might be confronted with a high number of false alarms.
In this case please refer to 5.5.2 for employing external PIR motion detection sensors.
5.5.2 ALARM/ACTIONS
ing and send-to-FTP function (s. 5.5.6) - one SD card is included in the delivery.
For video as well as picture recordings the camera will create a folder on your SD card
with the date of the current day. If the SD card is full, the oldest day/folder will automati-
cally be deleted and with it all recordings in this folder. The bigger your MicroSD card is,
which you install in the camera, the more days (recordings) you can save on the SD card.
The camera automatically records videos with a length of 15 seconds. Since the camera
also supports prerecording, 2-3 seconds will be added to the recording. This way you will
be able to see 2-3 "before" the actual alarm event is happening.
The external output connects to a relay inside the camera that can be switched manually
or automatically in case of an alarm event. Please check Activate External Output to let
the camera open or close a circuit with an external device connected to the pins 1&2 (s.
page 5). The external output can be used with the cameras motion detection to activate
signaling devices like sirens or LED lights. It can also be used to control connected de-
vices manually, e.g. via our smartphone app. The relay can be connected to circuits with
up to 30 V direct current / 125 V alternating current and max. 1 A.alternating current
and max. 1 A.z
Adjust the cameras behaviour in case of a motion alert
trigger event. You can set the camera to send you an
email and to save snapshots or videos on your SD
card. Please make sure you set your SMTP server set-
tings before activating the email notification (s. 5.5.4
& 5.5.5) and that you have a SD card in your cameras
SDHC card slot (max. 32 GB) to use the video record-
You can use a motion detector like the IN-Motion 500 (out-
door) to improve the detection rate of your camera. Simply
connect the sensor to the alarm input and activate the external
input. An alarm will be triggered once the circuit (pins 3&4
- see page 5) is broken by the relay inside the detector (n.c.
"Normally Closed") or if the wire is disconnected. The state you
have to choose depends on your sensor - the wrong choice will
give a continous alert once the detector is connected. Please
refer to the Motion Detector user manual.
