Usage scenario: Radio code/s already saved
1. Connect the receiver switch to the mains. The LED indicator does not flash. Keep the button (1) on the
receiver switch pressed down until the LED indicator (2) starts to flash. The receiver switch is now in
learning mode for a new additional code.
2. Press the control button on the RSL radio transmitter. The on/off control buttons are often marked with
"ON" or "OFF". Pay attention to the details in the instruction manual for the transmitter you are using.
Keep the button on the RSL radio transmitter pressed down until the LED indicator next to the button
on the receiver switch stops flashing. The radio code for this transmitter is now recognised and saved.
3. The learning procedure has been successfully completed; the device exits automatically from the
learning mode.
4. Repeat these configuration steps to save more RSL radio transmitters until the maximum number of
transmitters that can be saved is reached.
b) Deleting saved radio transmitters from the receiver switch
You can clear all radio codes simultaneously, or if, for example, you want to use the switching channel of
a radio transmitter (wall-mounted switch or radio remote control) for another receiver switch, the switching
channel can be cleared individually. Pay attention to the details in the instruction manual for the transmitter
you are using.
Usage scenario: clear all radio codes
1. When the receiver switch has turned off the device, press the button until the LED indicator (2) starts to
blink. The receiver switch is now in learning mode.
2. Release the switch, then press again and hold until the LED indicator (2) goes off. All saved radio codes
are now deleted.
Usage scenario: delete an individual radio code
1. Hold down the receiver button (1) until the indicator LED (2) starts flashing.
2. Hold down the channel button (the button the channel was assigned to) on your remote control until the
indicator LED goes off.
c) Turning on/off using the button on the receiver switch
• For a functional test, the device connected to the receiver switch can also be switched on/off with the
button.
• Briefly press the button on the receiver switch to turn the device on (the LED on the receiver switch
illuminates) or off (the red LED goes off).
Functional test
• If you have not already done so, you must first train the receiver switch to connect to an RSL system radio
transmitter (e.g. a wall-mounted switch or a radio remote control).
• Ensure that the receiver switch is connected to the mains (230 V/AC 50 Hz) .
• Press the ON button on the RSL transmitter that the receiver switch was trained to connect to. The red
LED indicator on the receiver switch illuminates and the switching output is activated. The connected
device is turned on.
• To deactivate the switching output and turn off the connected device, briefly press the OFF button on the
RSL transmitter that the receiver switch was trained to connect to. The red LED on the receiver switch
turns off.
• If the functional test fails, delete the code, retrain the RSL switch and test again as described above.
Transmission range information
The transmission range is up to 70 m, depending on the RSL system radio transmitter used.
However, this transmission range value refers to the so-called "open area transmission
range". This transmission range denotes the idealized distance between the transmitter and
receiver within unhindered and direct eye contact and without disruptive influences. In practice,
however, there are walls, ceilings and other structures between the transmitter and receiver,
which correspondingly reduce the transmission range. Due to the different effects these have
on radio transmission, it is unfortunately not possible to guarantee a specific transmission
range. Nevertheless, the device can normally be operated without problems in a detached
house.
The transmission range can be significantly reduced by:
• Walls, reinforced concrete ceilings
• Laminated/metallized insulating glass
• Proximity to metal and conductive objects (e.g. radiators)
• Proximity to the human body
• Broadband interference, e.g. in residential areas (DECT cordless phones, mobile phones, wireless
headphones, wireless speakers, wireless weather stations, baby monitoring systems etc.)
• Proximity to electrical motors, transformers, power adaptors and computers
• Proximity to poorly covered or open computers or other electrical devices
Maintenance and cleaning
This product is maintenance-free, never open/dismantle it. Consult a technician for maintenance or repair.
Declaration of Conformity (DOC)
We, Conrad Electronic SE, Klaus-Conrad-Straße 1, D-92240 Hirschau, hereby declare that this product
conforms to the fundamental requirements and the other relevant regulations of the directive 1999/5/EC.
The Declaration of Conformity for this product can be found at www.conrad.com.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the household waste.
At the end of its service life, dispose of the product according to the relevant statutory regulations.
You thus fulfil your statutory obligations and contribute to the protection of the environment.
Technical data
Operating voltage ............................. 230 V/AC, 50 Hz
Switching power ............................... 3500 W (ohmic load), 600 W (inductive load)
Receiving frequency ......................... 433 MHz
Transmission range .......................... max. 70 m (see "Transmission range information")
Operating conditions ......................... 0 to +45 °C, 0 - 90 % RH (non-condensing)
Storage conditions ............................ 0 to +45 °C, 0 - 90 % RH (non-condensing)
Dimensions (W x H x D) ................... 41 x 41 x 18 mm
Weight .............................................. 32 g
Compatible radio remote controls ..... Item no. 526925, 640305, 640369, 640374, 640375, 640378, 646467,
646477, 646488, 646602, 646614, 646655, 751901 (Conrad Item no.)
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau
(www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming,
or the capture in electronic data processing systems require the prior written approval by the editor.
Reprinting, also in part, is prohibited. This publication represent the technical status at the time of
printing.
© Copyright 2015 by Conrad Electronic SE.
V3_0315_02_JH
