SET MENU
4 D. RANGE (dynamic range)
Use this feature to adjust the dynamic range. This setting
is effective only when this unit is decoding Dolby Digital
signals.
Choices: MAX, STD (standard), MIN (minimum)
MAX
Select the "MAX" for feature films.
STD
Select the "STD" for general use.
MIN
Select the "MIN" for listening to sources at low volume
levels.
5 L/R BALANCE (balance of the
main left and right speakers)
Use this feature to adjust the balance of the output level
from the main left and right speakers.
Control range: 20 steps for L/R
Initial setting: 0 dB for L/R
1
Press i to decrease the output level for the
main left speaker. Press j for the main right
speaker.
6 HP TONE CTRL (headphone tone
control)
Use this feature to adjust the level of the bass and treble
when you use your headphones.
Control range (dB):
BASS ............... –6 to +3
TRBL (treble) .. –6 to +3
Initial setting:
BASS ............... 0 dB
TRBL ............... 0 dB
46
7 I/O ASSIGN (input/output
assignment)
It is possible to assign jacks according to the component
to be used if this unit's COMPONENT VIDEO input jack
or DIGITAL INPUT/OUTPUT jack settings (component
names for jacks) differ from that component. This makes
it possible to change the jack assignment and effectively
connect more components.
Once you assign, you can select that component with
INPUT l / h (or the input selector buttons on the
remote control).
I 7A CMPNT-V INPUT for
COMPONENT VIDEO INPUT jacks
[A] and [B]
[A] DVD, V-AUX, VCR 2/DVR, VCR 1,
Choices:
D-TV/CBL
[B] DVD, V-AUX, VCR 2/DVR, VCR 1,
D-TV/CBL
I 7B OPTICAL OUT for OPTICAL
OUTPUT jack (1)
(1) MD/CD-R, (
Choices:
CD, V-AUX, VCR 2/DVR, VCR 1,
D-TV/CBL, DVD
I 7C OPTICAL IN for OPTICAL
INPUT jacks (2) to (4)
Choices: (2) MD/CD-R, (
CD, VCR 2/DVR, VCR 1, D-TV/
CBL, DVD
(3) MD/CD-R, (
CD, VCR 2/DVR, VCR 1, D-TV/
CBL, DVD
(4) MD/CD-R, (
CD, VCR 2/DVR, VCR 1, D-TV/
CBL, DVD
I 7D COAXIAL IN for COAXIAL
INPUT jack (5)
Choices: (5) MD/CD-R, (
CD, V-AUX, VCR 2/DVR, VCR 1, D-
TV/CBL, DVD
Notes
• You cannot select an item more than once for the same type of
jack.
• When you connect a component to both the COAXIAL and
OPTICAL jacks, priority is given to the input signals from the
COAXIAL jack.
TUNER),
DSP-AX630SE
TUNER),
DSP-AX630SE
TUNER),
DSP-AX630SE
TUNER),
DSP-AX630SE
TUNER),
DSP-AX630SE
